+ Explore opens the query workspace, where you write SQL against a dashboard’s connections, look at the results, chart them, and add the chart to the dashboard as a tile. It is how new tiles get made in the browser. The pencil on an existing tile still opens that one tile for direct editing.
On a dashboard, + Explore sits in the top bar next to Edit. On the dashboard list it opens the workspace for the only dashboard, or asks which one to use when there are several, because a dashboard supplies the connections, the filter definitions, and the destination for new tiles.
Write and run a query
The workspace opens with a query tab. Type SQL and press Run, or ⌘ ⏎ (Ctrl ⏎ on Linux).
SELECT region, ROUND(SUM(amount), 2) AS revenue
FROM orders
GROUP BY region
ORDER BY revenue DESC
The sidebar’s Sources section lists the tables and columns of the selected connection. Filter it by name, and click a table or column to insert it at the cursor. Metrics lists the project’s governed metrics, and picking one opens a Metric tab where you choose its dimensions and grain, so a tile built from it stays tied to the definition rather than to copied SQL.
A tab can also be a Text tab for a markdown tile, and Download CSV saves the result of the current run.
Chart it and add it to the dashboard
Beside the results, the chart builder picks a chart type and its columns. Name the tile and click Add to dashboard. The tile lands in the dashboard’s YAML with the query and chart settings, as an ordinary diff.
The tab stays open after you add it. Choose another chart type and click Add another tile to put a second view of the same result on the dashboard. Both tiles reference one SQL definition, each with its own chart settings.
Save it for later
Save query keeps the SQL in the project’s query library without creating a tile. The library appears under Saved queries in the sidebar, grouped by connection, and any dashboard in the same project can open it, as long as the connection and the filter definitions the query needs are compatible.
Where things are kept
| what | where |
|---|---|
| Open tabs and drafts | Your browser’s local storage, scoped to the project and dashboard. Up to twenty tabs. |
| Saved queries | .sqldash/queries/<id>.yaml in the project, with readable SQL, a title, the source reference, and the filter definitions it needs. |
| Tiles you add | The dashboard’s own YAML, under queries: and the tile’s query:. |
Drafts survive a reload, including their SQL, source, and chart settings, but results never run on their own after a reload. Download drafts saves them as a file when the browser cannot keep them. Closing a tab that is still running cancels its query.
Adding a saved query to a dashboard copies its SQL and source into that dashboard rather than linking to the library file. Renaming or deleting a library query leaves those copies alone. When you edit SQL that several tiles share, the workspace lists the tiles that use it and offers a copy for the current tile, so an edit never repoints a tile you did not mean to change.
Pick the role, database, and warehouse
The Sources section starts with a connection picker, which lists the dashboard’s connections and the project’s. Under it, a Role picker shows the roles the connection can switch to, on the engines that have session roles, which are Snowflake, Postgres, MySQL, MariaDB, Trino, and ClickHouse over HTTP. SQL Server and Redshift show the roles that apply without offering a switch, and DuckDB, SQLite, BigQuery, Athena, and Databricks say what governs access instead.
On Snowflake the section also has Database and Warehouse pickers, and the role picker is labelled Primary role. What you pick applies to the current tab only. See Sources for how each one behaves, including what happens when a role cannot use the connection’s warehouse or database.
A tile added from a tab with a picked role, database, or warehouse keeps that choice.
The connection is copied into the dashboard’s source: map under a name that says what
was picked, with the role, database, and warehouse written into it, so the tile runs the
same way for everyone who serves the dashboard.
Who can run what
Anyone who can load a served dashboard can type SQL here, with the credentials of the
person running sqldash serve. On a warehouse, that credential’s grants are the
boundary. A DuckDB source has no credential of its own, so sqldash confines it to the
project’s own folders, as described in Sources.
